YB-WZ100 Automatic cartoning machine

暂无价格
收藏
  • 商品说明

Machine performance feature:

1. This machine is suitable for syrup/oral liquid bottle, serum bottle, essential oil bottle, e juice bottle, eye drops bottles, medicine board and other similar items of automatic cartoning.

3. We use high-quality stainless steel to make machine shell, the working surface closed by the plexiglass doors and windows, in strict accordance with the pharmaceutical industry "GMP" standard to be innovative design.

4. With no manual/leaflet automatic rejection function (optional); automatically stop when product into carton is not in place or no carton.

5. Easy to replace the different specifications of the product.

6. PLC control system, color touch screen display, the machine has an automatic count, fault alarm function.


Technical parameters:

Model

YB-WZ100

Capacity

20-100 cartons/min

Power supply

1Ph 220V, 50/60Hz

Main motor power

1.5 KW

Gas consumption

5-8L/min

Press air

0.6-0.8 MPA

Carton paper

250-350g/

Carton Specification

L 30-220mm x W 20-28mm x H 12-55mm (can be customized size)

Leaflet/Instruction book specification (optional)

50-60g/

Net weight

About 1000kg

Overall Dimension

L2400 × W1300 × H1650mm







×
